1320 Detectors
Flame Ionization Detector (FID)
6 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Flame Ionization Detector (FID)
Description Part no. Qty
1. Collector assembly: G1531-60690 1
2. PTFE chimney (optional) 19231-21050 –
3. Collector nut 19231-20940 1
4. Spring washer 3050-1246 1
5. Ignitor castle
or optional hastelloy component
19231-20910
19231-21060
1
1
6. Ignitor (glow plug) assembly 19231-60680 1
6A. Ignitor cable assembly G1531-60680
7. Upper/Lower collector insulator G1531-20700 2
8. Collector body G1531-20690 1
9. Spanner nut (collector) 19231-20980 1
10. Collector mount G1531-20550 1
11. Collector housing G1531-20740 1
12. Gasket 0905-0915 1
13. Screw, M4 × 25 mm, Torx, T20 0515-2712 3
14. Screw, M4 × 10 mm, Torx, T20 0515-2495 5
15. Interconnect clamp 19231-00040 2
16. FID interconnect assembly G1531-60715 1
17. FID signal board G1531-60010 1
18. FID interface board G1531-60020 1
19. Screw (captive) M4 × 20 mm, Torx, T20 1390-1024 4
20. Mounting pallet G1531-40020 1
21. Base spanner nut 19231-20990 1
22. Thermal strap G1531-00100 1
23. Jets: 1
Packed column FID
– Capillary column (0.011-inch id) 19244-80560 1
– Packed column (0.018-inch id) 18710-20119 –
– High temp (for use in simulated distillation, 0.018-inch id) 19244-80620 –
Capillary only FID
– Fused silica capillary/530µ (0.011-inch id) G1531-80560 1
– High temp jet (0.018-inch id) G1531-80620 –
24. Base weldments: 1
Packed column FID G1531-80580 –
Capillary column FID (not shown) G1531-80630 –
25. Heater/Sensor assembly G1531-61140 1
26. Nut w/lock washer 0535-0043 2
27. FID block insulation G1531-00030 1
28. FID seal insulation
– Capillary G1531-00130 1
– Packed G1531-00160 1
29. Packed FID column adapters: 1
– FID/NPD capillary column 19244-80610 –
– FID/NPD 1/8-inch packed column 19231-80520 –
– FID/NPD 1/4-inch packed column 19231-80530 –
30. Nut warmer insulation, (order qty 3) 19234-60715 3
31. Nut warmer cup assembly 19234-60700 1
