1320 Detectors
Flame Ionization Detector manifold assemblys
8 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Flame Ionization Detector manifold assemblys
Description Part no. Qty
Type 1 Manifold
1. Non-EPC 2 way valve G1531-60530 3
2. O-Rings HPM8 (Order no. 5180-4181, 12/pkg) 0905-1039 10
3. Screw, M4 × 10 mm, Torx, T20 0515-2495 1
4. EPC control module assembly G1531-60520 1
5. Non-EPC control module assembly G1531-60500 1
6. Screw, M3 × 25 mm, Torx T10 0515-0683 6
7. Screw, M3 × 8 mm, Torx, T10 0515-0655 2
8. Make-up gas, manual forward pressure regulator
assembly
G1531-60570 1
8A. Pressure regulator, 0 to 100 psi G1531-60630 1
8B. FID manifold regulator brazement G1531-80520 1
8C. Supply gas jumper weldment G1531-80550 1
Type 2 Manifold
9. Replacement EPC manifold assembly (replaces either
type)
G1531-60720 1
To Next Page
