1320 Detectors
Microcell Electron Capture Detector (µECD)
18 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Microcell Electron Capture Detector (µECD)
Description Part no. Qty
1. Micro ECD top cover G2397-00011 1
2. ECD signal wire assembly 19233-60635 1
3. Anode/Ferrule/Nut assembly (specific license required) G2397-60540 1
4. ECD thermal cover G1533-00030 1
5. Thermal cover clip 19233-00095 1
6. EDC top insulation G1533-00020 1
7. Screw, M4 × 10 mm, Torx T20 0515-2495 3
8. Clamp, interconnect 19231-00040 1
9. Captive screw, detector pallet, M4 × 20 mm, T20, Torx 1390-1024 4
10. FID pallet G1531-40020 1
11. Screw, M4 × 45 mm, Torx T20 0515-2484 2
12. Microcell Electron Capture Detector assembly: 1
– General licensed ECD, new G2397-65500 –
– General licensed ECD, rebuilt G2397-69900 –
13. ECD block insulation G1533-00010 1
14. ECD seal insulation G1533-00080 1
15. Screw, M4 × 12 mm, Torx T20 0515-2496 1
16. ECD make-up gas adapter weldment assembly: G2397-80520 1
– Gigabore liner G2397-20540 –
– End cap 19233-20755 –
17. Ferrules, capillary columns: 1
– No hole (plug), graphitized-vespel 5181-7458 –
– Graphite, 0.5 mm id (10/pkg) 5080-8853 –
– Graphite, 1.0 mm id (10/pkg) 5080-8773 –
18. Capillary column nut (2/pkg) 5181-8830 1
19. Screw, M4 × 12 mm, Torx T20, chromeplate 0515-2711 2
20. ECD interconnect assembly G1533-60510 1
21. Micro ECD signal PCB assembly G2397-60010 1
22. Micro ECD interface PCB assembly G2397-60020 1
23. Heater/Sensor assembly G1533-60625 1
24. Upper heated block G1533-20525 1
25. Lower heated block 19233-20515 1
26. ecd mounting plate G1533-00050 1
NS Nut warmer assembly 19234-60720 1
27. Nut warmer insulation 19234-60715 1
28. Nut warmer cup assembly 19234-60700 1
29. Tubing tygon (30 in.) 0890-0934 1
30. Vent elbow (if present) 19303-20590 1
31. Tubing adapter (if present) 5020-8231 1
