1320 Detectors
Microcell Electron Capture Detector manifold assembly
20 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Microcell Electron Capture Detector manifold assembly
Description Part no. Qty
Type 1 Manifold
1. O-rings HPM8 0905-1493 13
2. Screw, M4 × 8 mm, Torx, T20 0515-0910 1
3. EPC Micro ECD manifold assembly G2397-60550 1
NS Screw, M3 × 25 mm, Torx, T10 0515-0683 8
NS Screw, M3 ×.5 × 8 mm, Torx, T10 0515-0655 2
4. ECD make-up gas assembly G2397-20540 1
Chemical traps G1533-80540 2
Type 2 Manifold
5. Replacement EPC manifold assembly (replaces either
type)
G2397-60720 1
