1320 Detectors
Flame Photometric Detector jet and transfer tube assemblies
24 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Flame Photometric Detector jet and transfer tube assemblies
Description Part no. Qty.
1. O-ring, Kalrez, transfer tube 0905-1101 1
2. Transfer tube 19256-80550 1
3. Gigabore liner/ferrule assembly 19256-60590 1
4. Base assy, weldment G1535-80510 1
5. Heater/sensor assembly G1535-60620 1
6. Lower heater block 19256-20500 1
7. O-ring (Kalrez), jet cartridge 0905-1103 1
8. Jet cartridge G1535-80500 1
9. Ferrule, Vespel, 1/4-inch ID (Order no. 5080-8774) 0100-1061 1
10. Nut, brass, 1/4-inch 0100-0056 1
