1330 Covers
Metal covers
2 of 8
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Metal covers
Description Part no. Qty.
1. Screw, M4 × 12 mm, Torx T20 0515-2496 8
2. Manifold, RFI plate G1530-00470 1
3. Rear top panel G1530-00225 1
4. Rear bottom panel G1530-00035 1
5. Oven exhaust deflector (optional) G1530-80650 1
6. Inlet chassis (PTV) G2517-20550 –
7. Detector blank cover/insul. kit (not shown) G1530-67040 –
8. Inlet blank cover/insul. kit (not shown) G1530-67050 –
9. MIO/INET blank cover plate (not shown) G1530-00610 –
10. Shipping container for 6890 GC mainframe (not shown) G1530-80075 –
11. Panel for ALS slots (not shown) G1530-00710
