1340 Oven
Oven assembly
2 of 10
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Oven assembly
Description Part no. Qty.
1. Oven door G1530-60815 1
2. Fan blade, stainless steel, and set screw 05890-80270 1
3. Oven heater shroud assemblies: 1
–120V USA power G1530-61610
–200V Japan power G1530-61620
–220V Single phase power, Europe, and
208V USA power, single phase
G1530-61630
–220V Single phase power, Hong Kong G1530-61630
–220V Single phase power, China G1530-61630
–220V China power, slow ramp G1530-61230
–220V Israel power G1530-61630
–230V Single phase power, Switzerland, 10 amp G1530-61670
–230V Denmark power, 10 amp G1530-61670
–230V Denmark/Switzerland power, 16 amp G1530-61650
–230V Continental Europe power G1530-61650
–240V Australia power G1530-61640
–240V South Africa/India power G1530-61640
–240V Great Britain/Ireland power G1530-61640
–240V USA power G1530-61640
–240V Australia power, slow ramp G1530-61640
4. Screws, M4 × 0.7, Torx T-20, chrome plated 0515-2711 4
5. Hex nut 0535-0043 3
6. Washer 2190-0712 6
7. Sensor door assembly G1530-80670 1
8. Hinge pin G1530-20685 1
9. Oven motor assembly G1530-61310 1
10. On/Off switch rod G1530-40010 1
11. Keyboard bezel assembly G1530-60745 1
NS Rubber keypad G1530-40095 1
NS Keyboard flex membrane assembly G1530-80590 1
NS Keyboard display cable G1530-60540 1
12. Keyboard display 4 × 20 UF G1530-80000 1
13. Keyboard window bezel (plastics) G1530-61320 1
NS Glacier grey touch-up paint 6010-1497 –
NS Oven sensor G1530-61030
NS Column hanger 1460-1919
