1340 Oven
CO
2
cryogenic cooling
6 of 10
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
CO
2
cryogenic cooling
Description Part no. Qty.
1. LCO
2
blast brazement G1535-80550 1
2. Tee-union, brass 0100-0090 1
3. 1/8-inch Male conn. w/o O-ring G1543-80025 1
4. Screw, MS 8-32,.312 LG 2510-0043 2
5. Cryo bracket G1565-00010 1
6. Gland seal, LCO
2
G1565-20590 1
7. CO
2
cryo valve G1565-60545 1
8. CO
2
cryo inline filter 3150-0602 1
9. CO
2
inlet tube G1565-20600 1
10. Cryo blast restrictor weldment G1565-80590 1
11 . LC O
2
weldment G1565-80505 1
12. Clamp screw G1565-20560 1
NS Scr-mach T-20, Torx, M4 × 12 mm 0515-2496 2
NS TFE seal G1565-20840 1
NS CO
2
cryogenic kit G1565-65510 –
NS LCO
2
cryo blast kit G1565-65520 –
NS CO
2
cryo VLV/Dual blast assembly G1565-65521 –
