1350 Valves
Valve box assembly
2 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Valve box assembly
Description Part no. Qty.
1. Screw, M4 × 8 mm, Torx T-20, chromeplated 0515-2711 6
2. Valve box cover G1580-00030 1
3. Valve box insulation, top G1580-00050 1
4. Insulation retainer plate G1580-00040 1
5. Hex nut, insulation plate 0535-0025 2
6. Screw, M3 × 30 mm, Torx T-10, chromeplated htr (blk) 0515-2525 4
7. Heater block G1580-20520 2
8. Standoff, valve box G1580-20500 2
9. Valve box bottom plate G1580-00010 1
10. Screw, M3 × 8 mm, Torx T-10, chromeplated 0515-2726 2
11. Heater/Sensor harness cable clamp 1400-0015 2
12. Heater/Sensor assembly G1580-61140 2
13. Cable-tie strap (not shown) 1400-0249 4
14. Aluminum tube (split/splitless inlet only) (not shown) 18900-20320 1
15. In-line filter (sample in line) (not shown) 0101-0532 1
