1350 Valves
Valve driver assembly
4 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Valve driver assembly
Description Part no. Qty.
1. Valve driver bracket G1580-00070 1
2. Captured screw, M4 × 12 mm, Torx T-20 1390-1023 2
3. Valve driver wiring harness G1530-60660 1
4. Pneumatic tubing, 1/8-inch OD, Teflon 0890-0746 8
5. Adapter fitting, 10/32 × 1/16-inch hose barb 0100-1205 8
6. Standoff (included with valves) — 8
7. 4-way Solenoid valves G1580-61090 4
8. O-ring (with valves and end plate kit) — 10
9. Solenoid valve end plate kit 05890-61097 1
10. Screw, skt hd cap 0515-1214 2
11. Elbow fitting, 1/4-inch, male 0100-1632 2
12. Exhaust tubing, 1/4-inch OD, 120 inch 0890-1489 1
13. Heater cable assembly (not shown) G1530-60790 1
