1350 Valves
Valve actuator assembly (2 of 2)
8 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Valve actuator assembly (2 of 2)
Description Part no. Qty.
1. Dowel pin 1480-0017 1
2. Socket head screw, M4 x 8-mm 0515-0153 3
3. Link 19325-80010 1
4. Piston rod 19325-20650 1
5. Teflon tubing, 1/8-inch o.d. x 42-inch for actuators 0890-0746 1
6. Hose fitting 0100-1205 2
7. O-ring, 0.239-inch ID 0905-0103 1
8. Actuator cylinder 19325-20630 1
9. Piston 19325-20640 2
10. O-ring, 1.046-inch ID 0905-0463 1
11. O-ring, 1.176-inch ID 0905-1405 1
12. Cylinder end cap 19325-20680 1
13. Elbow fitting 0100-1220 1
