1360 Electrical
AC Power components
2 of 16
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
AC Power components
Description Part no. Qty.
1. Transformer, universal* G1530-60970 1
2. Screw, MS M5 × 0.8 Torx,T-25* 0515-1538 4
3. AC printed circuit board assembly** (See Figure 1360-2) G1530-60050 1
4. Power cable assemblies: 1
– USA and Canada 120V G1530-60870
– Japan 200V G1530-60920
– USA 208V 8121-0075
– Continental Europe, 220V single phase power G1530-60885
– Hong Kong, 220V, single phase G1530-67505
– China 220V G1530-67506
– China 220V, 10 amp slow ramp G1530-61180
– Israel 220V G1530-67507
– Switzerland/Denmark, 230V, 16A G1530-67503
– Switzerland power cable, 230V, 10A G1530-67500
– Denmark, 230V, 10A G1530-67502
– Continental Europe, 230V G1530-60880
– Australia, 240V G1530-60910
– South Africa/India, 240V G1530-67501
– United Kingdom/Ireland, 240V G1530-60890
– USA and Canada, 240V G1530-60900
– Australia, 240V G1530-61170
5. AC control cable G1530-60760 1
6. On/Off rod G1530-40010 1
7. Hex nut/lock washer 0535-0043 1
8. Hexbolt, M6 × 1 × 100 mm 0515-2667 1
9. Transformer, universal G1530-60975 1
10. Transformer bracket G1530-00730 1
11. Cable, pigtail, 6890N ALS power*** G1530-61590** 1**
*For GC ’s with serial number <10225
** Order AC Printed Circuit Board replacement kit G1530-61350.
The kit contains one AC board one triac, and required hardware.
See Figure 1360-1.
*** Cable used only on early model 6890N GCs to patch sampler power from
transformer into J7 on main board.
