1360 Electrical
AC Power circuit board
4 of 16
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
AC Power circuit board
Description Part no. Qty.
1. AC Power board assembly* G1530-60050 1
2. Triac cable assy (3 Jumpers) G1530-60750 1
3. AC configuration plug 1
– USA and Canada 120V G1530-60690
– Japan 200V G1530-60700
– Continental Europe, 220V single phase power G1530-60710
– Hong Kong, 220V, single phase G1530-60710
– China 220V G1530-60710
– China 220V, 10 amp slow ramp G1530-60710
– Israel 220V G1530-60710
– Switzerland/Denmark, 230V, 16A G1530-60720
– Switzerland power cable, 230V, 10A G1530-60720
– Denmark, 230V, 10A G1530-60720
– Continental Europe, 230V G1530-60720
– Australia, 240V G1530-60730
– South Africa/India, 240V G1530-60730
– United Kingdom/Ireland, 240V G1530-60730
– USA and Canada, 240V G1530-60730
– Australia 240V, slow ramp G1530-60730
4. Mounting screw, M4 × 25 mm, Torx, T-20 0515-2712 1
5. Fuses (not shown): 2
– Fuse 20A 250V (USA and Canada 120V) 2110-0098
– Fuse 15 amp (Japan 200V) 2110-0054
– Fuse 15 amp (Cont. Eur. 220V single phase) 2110-0054
– Fuse 15 amp (Hong Kong 220V single phase) 2110-0054
– Fuse 15 amp (China 220V) 2110-0054
– Fuse 15 amp (China 220V slow ramp) 2110-0054
– Fuse 15 amp (Israel 220V) 2110-0054
– Fuse 15 amp (Switzerland 230V 10A single phase) 2110-0054
– Fuse 15 amp (Denmark/Switzerland 230V 16A) 2110-0054
– Fuse 15 amp (Denmark 10 amp) 2110-0054
– Fuse 15 amp (Continental Europe 230V) 2110-0054
– Fuse 15 amp (Australia 240V) 2110-0054
– Fuse 15 amp (South Africa/India 240V) 2110-0054
– Fuse 15 amp (United Kingdom/Ireland 240V) 2110-0054
– Fuse 15 amp (USA and Canada 240V) 2110-0054
– Fuse 15 amp (Australia 240V, slow ramp) 2110-0054
6. Lock washer 2190-0321 3
7. Glass fuse, type F, 8A/250V 2110-0036 2
* Order AC Printed Circuit Board replacement kit G1530-61350. The kit contains
one AC board, one triac, and required hardware. See Figure 1360-2.
