10-18 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-4 CAL, Functions, 8712ES and 8714ES (3 of 3)
1. Pressing this softkey begins a guided 2-port calibration procedure, using seven
standards. When the calibration is complete, the command *WAI;:SENS[1|2]
:CORR:COLL:SAVE;*WAI is executed. The order of appearance and the content of
the softkey menus depend on the measurement channel 1 and measurement chan-
nel 2 configurations.
KEYSTROKES SCPI COMMAND
CAL, (Transmissn) (continued)
User 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
Default 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
User 2-Port SENS[1|2]:CORR:COLL:IST OFF;METH TWOP;
*WAI
Measure Standard
1
SENS[1|2]:CORR:COLL STAN[1|2|...|7];*WAI
Isolation on OFF SENS[1|2]:ISOL [ON|OFF];*WAI
Normalize on OFF TRAC CH[1|2]SMEM,CH[1|2]SDATA;:CALC[1|2]:
MATH (IMPL/CH[1|2]SMEM);:DISP:WIND[1|2]:
TRAC[1|2] ON;TRAC[1|2] OFF
More Cal
(see Table 10-11 on page 10-26)
(menu selection only)
See Table 10-11 on page 10-30 for Test Set calibration.
See Table 10-7 on page 10-22 for Fault Location calibration.
See Table 10-8 on page 10-23 for SRL calibration.
See Table 10-9 on page 10-24 for Power or Conversion Loss calibration.
