Agilent Technologies 8720E Series Programmer's Guide

Chapter 1 1-213
Alphabetical Command Reference
S
S
Syntax
S<11|12|21|22>; or S<11|12|21|22>?;
Description
Front Panel Equivalents
Command Description Range Query Response
S11
Forward reflection measurement
1
(See also “RFLP.”)
1. The S11 command can also be used on ET models to set the measurement mode to “Reflection.”
N/A
<0|1><
L
F
>
S12
Reverse transmission measurement
2
2. The S12 and S22 commands do not apply to ET models.
N/A
<0|1><
L
F
>
S21
Forward transmission measurement
3
(See also “TRAP.”)
3. The S21 command can also be used on ET models to set the measurement mode to “Transmissn.”
N/A
<0|1><
L
F
>
S22
Reverse reflection measurement
2
N/A
<0|1><
L
F
>
Command Hardkey Softkey
S11
S12
S21
S22
Meas
Refl:FWD S11 (A/R)
Meas
Trans:REV S12 (A/R)
Meas
Trans:FWD S21 (B/R)
Meas
Refl:REV S22 (B/R)
