1-99
Making Measurements
Using Test Sequencing
Figure 1-77 Test Sequencing Help Instructions
2. To select a sequence position in which to store your sequence, press:
This choice selects sequence position #1. The default title is SEQ1 for this sequence.
Refer to "Changing the Sequence Title" on page 1-103 for information on how to modify
a sequence title.
3. To create a test sequence, enter the parameters for the measurement that you wish to
make. For this example, a SAW filter measurement is set up with the following
parameters:
Use the front panel knob to scroll until Preset State is highlighted on the display.
or
Save/Recall
Meas
Format
Center 134 M/µ
Span 50 M/µ
Scale Ref
