1-104
Making Measurements
Using Test Sequencing
Storing a Sequence on a Disk
1. To format a disk, refer to Chapter 4 , “Printing, Plotting, and Saving Measurement
Results.”
2. To save a sequence to the internal disk, press:
and select the particular sequence softkey.
The disk drive access light should turn on briefly. When it goes out, the sequence has
been saved.
CAUTION The analyzer will overwrite a file on the disk that has the same title.
CAUTION Do not mistake the line switch for the disk eject button.
Loading a Sequence from Disk
For this procedure to work, the desired file must exist on the disk in the analyzer drive.
1. To view the first six sequences on the disk, press:
• If the desired sequence is not among the first six files, press:
until the desired file name appears.
2. Press the softkey next to the title of the desired sequence. The disk access light should
illuminate briefly.
NOTE If you know the title of the desired sequence, you can title the sequence (1–6)
with the name, and load the sequence. This is also how you can control the
sequence number of an imported titled sequence.
Purging a Sequence from Disk
1. To view the contents of the disk (six titles at a time), press:
• If the desired sequence is not among the first six files, press:
until the desired file name appears.
2. Press the softkey next to the title of the desired sequence. The disk access light should
illuminate briefly.
Seq
Seq
Seq
