Agilent Technologies 8720E Series User Manual

1-119
Making Measurements
Using Test Sequencing to Test a Device
This will create a displayed list for sequence 2, as shown:
Start of Sequence
INTERNAL DISK
DATA ARRAY
ON
FILENAME
FILE 0
SAVE FILE
3. To create a sequence that prompts you to tune a device that has failed the limit test,
and calls sequence 1 to retest the device, press:
This will create a displayed list for sequence 3, as shown:
Start of Sequence
TITLE
TUNE DEVICE
SEQUENCE
PAUSE
DO SEQUENCE
SEQUENCE 1
You will see the “tune device” prompt in the title area or the sequence will pause until you
press the key.
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 3 SEQ3
Display
MORE
TITLE
T
U
N
E
D
E
V
I
C
E
DONE
Seq
SPECIAL FUNCTIONS
PAUSE
RETURN
DO SEQUENCE
SEQUENCE 1 SEQ1
Seq
DONE SEQ MODIFY
CONTINUE SEQUENCE
