Using Test Sequencing to Test a Device
To create a second sequence that will perform a desired measurement function,
decrement the loop counter, and call itself until the loop counter value is equal to
zero, press:
or on ET models:
This will create a displayed list as shown:
SEQUENCE LOOP 2
Start of Sequence
Trans:FWD S21 (B/R)
SCALE/DIV
AUTO SCALE
MKR Fctn
SEARCH MAX
DECR LOOP COUNTER
IF LOOP COUNTER <> 0 THEN DO
SEQUENCE 2
To run the loop sequence, press:
Generating Files in a Loop Counter Example Sequence
This example shows how to increment the names of files that are generated by a sequence
with a loop structure.
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 2 SEQ2
Meas
Trans: FWD S21 (B/R)
TRANSMISSN
Scale Ref
AUTO SCALE
Marker Search
SEARCH: MAX
Seq
SPECIAL FUNCTIONS
DECISION MAKING
DECR LOOP COUNTER
IF LOOP COUNTER 0
SEQUENCE 2 SEQ2
Seq
DONE SEQ MODIFY
Preset
SEQUENCE 1 SEQ1
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 1 SEQ 1
SPECIAL FUNCTIONS
DECISION MAKING
LOOP COUNTER
7 x1
Save/Recall
SELECT DISK
INTERNAL DISK
RETURN
DEFINE DISK-SAVE
DATA ONLY ON
Local
SET ADDRESSES
PLOTTER PORT
DISK
Seq
DO SEQUENCE
SEQUENCE 2
DONE SEQ MODIFY
NEW SEQ/MODIFY SEQ
SEQUENCE 2 SEQ 2
