Making Mixer Measurements (Option 089 Only)
Conversion Loss Using the Frequency Offset Mode
Performing a Power Meter (Source) Calibration Over the RF Range
1. Calibrate and zero the power meter.
2. Set the power meter’s address:
(where aa is the GPIB address of the power meter)
3. Select the appropriate power meter by pressing until the correct
model number is displayed (Agilent 436A or Agilent 438A/437).
NOTE The Agilent E4418B and E4419B (EPM) power meters have a “437emulation”
mode which can be used in this procedure by following these steps.
• If you are using an Agilent EPM power sensor and your network analyzer
has firmware revision 7.72 or greater:
a. Select the remote interface command set on the power meter by
pressing the System Inputs key and the following softkeys: Remote
Interface, Command Set, SCPI
b. Skip step 4 and continue at step 5.
The power sensor factors are automatically read by the analyzer.
• If you are using an Agilent 848X-series power sensor or your network
analyzer does not have firmware revision 7.72 or greater:
a. Choose the 438A/437 selection on the network analyzer by pressing:
until it reads
b. Select the remote interface command set on the power meter by
pressing the System Inputs key and the following softkeys: Remote
Interface, Command Set, 437B
4. Press and
enter the correction factors as listed on the power sensor. Press
(where fff is the frequency of the calibration factor in MHz)
(where nnn is the calibration factor number) for each correction
factor. When finished, press .
SET ADDRESSES
ADDRESS: P MTR/GPIB
aa
x1
POWER MTR [ ]
Local
SET ADDRESSES
POWER MTR [ ]
POWER MTR: [438A/437]
Cal
PWRMTR CAL
LOSS/SENSR LISTS
CAL FACTOR
SENSOR A
ADD
FREQUENCY
fff M/µ
CAL FACTOR
nnn x1
DONE
DONE
