4-16
Printing, Plotting, and Saving Measurement Results
Defining a Plot Function
NOTE The peripheral ignores when you are plotting to a
quadrant.
Selecting Pen Numbers and Colors
• Press and select the plot element where you want to change the pen number.
For example, press and then modify the pen number. The pen
number selects the color if you are plotting to an HPGL/2 compatible color printer.
Press after each modification.
NOTE The following color assignments are valid for HPGL/2 compatible color
printers only. When using word processor or graphics presentation programs,
different colors may be assigned to the pen numbers.
NOTE You can set all the pen numbers to black for a plot in black and white.
You must define the pen numbers separately for each measurement channel
(channel 1/3 and channel 2/4).
Table 4-2 Default Pen Numbers and Corresponding Colors
Pen Number Color Pen Number Color
0white4 yellow
1 cyan 5 green
2magenta6 red
3blue7 black
Table 4-3 Default Pen Numbers for Plot Elements
Corresponding Key Plot Element Pen Numbers
Channel 1 Channel 2
Measurement Data Trace 2 3
Displayed Memory Trace 5 6
Graticule and Reference Line 1 1
Displayed Text 7 7
Displayed Markers and Values 7 7
AUTO-FEED ON
MORE
PEN NUM DATA
x1
PEN NUM DATA
PEN NUM MEMORY
PEN NUM GRATICULE
PEN NUM TEXT
PEN NUM MARKER
