1-102
Making Measurements
Using Test Sequencing
The following list is the commands entered in "Creating a Sequence" on page 1-98.
Notice that for longer sequences, only a portion of the list can appear on the screen at
one time.
Start of Sequence
RECALL PRST STATE
Trans: FWD S21 (B/R)
LOG MAG
CENTER
134 M/u
SPAN
50 M/u
SCALE/DIV
AUTO SCALE
3. To change a command (for example, the span value from 50 MHz to 75 MHz), move the
cursor (
→) next to the command that you wish to modify, press:
or
• If you use the key to move the cursor through the list of commands, the
commands are actually performed when the cursor points to them. This feature
allows the sequence to be tested one command at a time.
• If you wish to scroll through the sequence without executing each line as you do so,
you can press the key and scroll through the command list backwards.
4. To delete the current command (for example, span value), press:
5. To insert a new value (for example, 75 MHz), press:
6. Press to exit the modify (edit) mode.
Clearing a Sequence from Memory
1. To enter the menu where you can clear a sequence from memory, press:
2. To clear a sequence, press the softkey of the particular sequence.
75 M/µ
Seq
Seq
