2-20
Device Connection Example
16088-60002 Dual in line package (28 pin)
1
2
3 4
5
6
7
8
9
10
11
12
13
14 15
16 17 18
20
19
21
22
23
24
25
27
26
28
14
15
28
1
F
G
3
F
G
4
F
G
5
F
G
6
F
G
2
F
G
1
SMU
21
VMU
2
1
VSU
F
S
GNDU
F
2
F
1
PGU
Drain Gate Source Substrate
G
S
D
Sub
1 2 3 4
MOSFET: SD214DE
For all class exercises, you need the 28-pin dual in line socket which comes standard with the
4145 fixture (16058A) or the 4156 fixture (16442A/B). Either fixture works fine.
With the 16442A/B fixture, note that there are two SMU numbering schemes....3 SMUs with
force and sense, or six SMUs with force only. For this class example we will use the six (6) SMU
scheme.
To mount the MOSFET, the leads must be re-arranged into a straight line as shown.
IMPORTANT:
The MOS FET is highly sensitive to electrostatic damage. Touching the bare leads will definitely
destroy the device. The device comes with a special shorting wire attached. Bend the leads the
way you want, insert the device in the socket, and then remove the shorting wire. The wire has a
tab. Just grab the tab and pull straight out. The wire will spiral out as you pull.
