554 Chapter 16
W-CDMA Uplink Digital Modulation for Receiver Test
W-CDMA Uplink Concepts
Figure 16-74 ESG I/O Connectors for W-CDMA Uplink
Refer to Table 16-5 for descriptions on connector assignments when using W-CDMA uplink in DPCH
mode. For PRACH mode, refer to Table 16-6 on page 556.
Table 16-5 Connector Descriptions for DPCH Mode
Connector Label Connector Type Input/Ou
tput
Assigned Signal
PATTERN
TRIGGER IN
BNC Input Frame sync trigger. This signal determines the
SFN frame timing of the ESG so it is
synchronous with the base station.
