Chapter 4: Sealing plates
PlateLoc User Guide
70
4. Gas-Purging PlateLocs only. In the Special Menu, set the Argon Fill
Time
(in seconds).
The Argon Fill Time parameter is the amount of time the plate will
be exposed to argon before the plate is sealed.
5. Press Done to save the new settings and return to the Main Menu.
6. Wait for the temperature to reach within 2 °C of the specified value.
To monitor the current temperature and status, on the
Main Menu:
Check Seal Temp for the current temperature.
Check Status to see if the PlateLoc is warming up or cooling
down.
Note: The RUN button on the touch screen is unavailable until the
the hot plate temperature is within 2 °C of the specified value.
Lab automation
system procedure
In the Velocity11 lab automation system software, you set the sealing
parameters when you are setting the PlateLoc task parameters. For
detailed instructions, see the lab automation system software user guide,
such as the VWorks User Guide.
The seal time and temperature you specify depends on the type of plate
and the type of seal you are using. The table in “Standalone device
procedure” on page 68 shows the settings you can use as a starting
point. For the most up-to-date startup settings, the PlateLoc Thermal Plate
Sealer Seal Selection Guide. You can locate the guide on the Velocity11
website at www.velocity11.com.
00207
PlateLoc
screen menu 2
00207
PlateLoc
screen menu 2
Special Menu
Argon Fill Time: 3.0s
Service Done
Press arrows to set
argon fill duration.
00206
PlateLoc
screen menu 1
Main Menu
Seal Time: 1.8s
Set Time: 1.8 Seconds
Set Temp: 160 Degrees C
Air pressure: 89 psi
Seal Temp: 85°C
Status: Warming Up
Setup
Check current temperature.
Check the device status.
RUN button is blank.
