4 Characteristics and Specifications
Electrical Specifications
86 U1731C/U1732C/U1733C User’s Guide
Source impedance of inductance measurement
Table 4 - 9 Source impedance of inductance measurement
Range Typical source impedance
100 Hz 120 Hz 1 kHz 10 kHz 100 kHz
All models All models All models U1733C and
U1732C only
U1733C only
20 μH - - - 100 Ω 100 Ω
200 μH- - 100 Ω 100 Ω 100 Ω
2000 μH100 Ω 100 Ω 100 Ω 100 Ω 100 Ω
20 mH 100 Ω 100 Ω 100 Ω 100 Ω 100 Ω
200 mH 100 Ω 100 Ω 100 Ω 1 kΩ 1 kΩ
2000 mH 100 Ω 100 Ω 1 kΩ 10 kΩ 1 kΩ
20 H 1 kΩ 1 kΩ 10 kΩ 10 kΩ 1 kΩ
200 H 10 kΩ 10 kΩ 100 kΩ 10 kΩ
[1]
-
2000 H 100 kΩ 100 kΩ 100 kΩ --
[1] This specification value is applicable for firmware versions 00.21 and above only. For firmware versions below 00.21, the im-
pedance value is set at 100 kΩ.
