4 Characteristics and Specifications
SMD Tweezers Specifications
88 U1731C/U1732C/U1733C User’s Guide
Electrical characteristics
Table 5 U1782B SMD tweezers electrical characteristics
Parameters Test condition 100 Hz 120 Hz 1 kHz 10 kHz 100 kHz
Cp
Parallel capacitance
Tweezers open <0.7 pF <0.7 pF <0.7 pF <0.7 pF <0.7 pF
Rs
Series resistance
Tweezers short <0.5 Ω <0.5 Ω <0.5 Ω <0.5 Ω <0.5 Ω
Ls
Series inductance
Tweezers short <1.2 µH <1.2 µH <1.2 µH <1.2 µH <1.2 µH
Notes:
1 The accuracy is specified at 23 °C ± 5 °C and <75% R.H.
2 You are recommended to perform an open/short calibration on the LCR meter before using the tweezers.
