Agilent Technologies U1731C

4 Characteristics and Specifications
Electrical Specifications
80 U1731C/U1732C/U1733C User’s Guide
Inductance specifications
Table 4 - 3 Inductance specifications
Range Resolution
Accuracy = A
L
+ Offset
100 Hz 120 Hz 1 kHz 10 kHz 100 kHz
All models All models All models
U1733C and
U1732C only
U1733C only
20 μH0.001 μH - - - 1.0% + 5 2.5% + 20
200 μH0.01 μH - - 1.0% + 5 0.7% + 3 2.5% + 20
2000 μH0.1 μH 0.7% + 10 0.7% + 10 0.5% + 3 0.5% + 3 0.8% + 20
20 mH 0.001 mH 0.5% + 3 0.5% + 3 0.2% + 3 0.3% + 3 0.8% + 10
200 mH 0.01 mH 0.5% + 3 0.5% + 3 0.2% + 3 0.2% + 3 1.0% + 10
2000 mH 0.1 mH 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5 1.0% + 10
20 H 0.001 H 0.2% + 3 0.2% + 3 0.5% + 5 1.0% + 5 2.0% + 10
200 H 0.01 H 0.7% + 5 0.7% + 5 1.0% + 5 2.0% + 8 -
2000 H 0.1 H 1.0% + 5 1.0% + 5 2.0% + 8 - -
