4 Characteristics and Specifications
Electrical Specifications
78 U1731C/U1732C/U1733C User’s Guide
Electrical Specifications
Impedance/Resistance/DCR specifications
NOTE
Specification assumptions are given on page 77.
Table 4 - 1 Impedance/Resistance/DCR specifications
Range Resolution
Accuracy = A
Z
+ Offset
DCR 100 Hz 120 Hz 1 kHz 10 kHz 100 kHz
U1733C only All models All models All models
U1733C and
U1732C only
U1733C only
2 Ω
[1]
0.0001 Ω 0.7% + 50 0.7% + 50 0.7% + 50 0.7% + 50 0.7% + 50 1.0% + 50
20 Ω
[1]
0.001 Ω 0.7% + 8 0.7% + 8 0.7% + 8 0.7% + 8 0.7% + 8 0.7% + 8
200 Ω
[1]
0.01 Ω 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5
2000 Ω 0.1 Ω 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5
20 kΩ 0.001 kΩ 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5
200 kΩ 0.01 kΩ 0.5% + 5 0.5% + 5 0.5% + 5 0.5% + 5 0.5% + 5 0.7% + 8
2000 kΩ 0.1 kΩ 0.5% + 5 0.5% + 5 0.5% + 5 0.5% + 5 0.7% + 5 -
20 MΩ
[2]
0.001 MΩ 2.0% + 8 2.0% + 8 2.0% + 8 2.0% + 8 5.0% + 8 -
200 MΩ
[2]
0.01 MΩ 6.0% + 80 6.0% + 80 6.0% + 80 6.0% + 80 - -
Notes:
1 The accuracy for the 2 Ω to 200 Ω range is specified after the Null function is used to subtract the resistance of test leads
and the contact resistance.
2 For the 20 MΩ and 200 MΩ range, the RH is specified for <60%.
3 Resistance measurement is specified to Q <10 and D >0.1; otherwise accuracy is specified as .
4 ESR (Equivalent Series Resistance) measurement is specified according to the impedance measurement and range. The
maximum display is up to 199.99 kΩ and the accuracy is specified as .
A
Z
Offset+()1 Q
2
+×
A
Z
Offset+()1 Q
2
+×
