U1731C/U1732C/U1733C User’s Guide III
Safety Symbols
The following symbols on the instrument and in the documentation
indicate precautions which must be taken to maintain safe operation of
the instrument.
Direct current (DC) Off (supply)
Alternating current (AC) On (supply)
Both direct and alternating current Caution, risk of electric shock
Three-phase alternating current
Caution, risk of danger (refer to this manual
for specific Warning or Caution information)
Earth (ground) terminal Caution, hot surface
Protective conductor terminal Out position of a bi-stable push control
Frame or chassis terminal In position of a bi-stable push control
Equipotentiality
Equipment protected throughout by
double insulation or reinforced
insulation
