Features and Functions 2
Additional Features
U1731C/U1732C/U1733C User’s Guide 41
When the input goes below the recorded minimum value or
above the recorded maximum value, the LCR meter beeps
and records the new value. The LCR meter also calculates
an average of all readings taken since the static recording
mode was activated.
From the LCR meter’s display, you can view the following
statistical data for any set of readings:
• Max: highest reading since the static recording mode was
enabled
• Min: lowest reading since the static recording mode was
enabled
• Avg: average or mean of all readings since the static
recording mode was enabled
• MaxMinAvg: present reading (actual input signal value)
Press the key for more than 1 second to enter the static
recording mode.
Figure 2-14 Using the Rec function
Press again to cycle through the Max, Min, Avg, or
MaxMinAvg (present) input values.
To exit this mode, press and hold the key for more than
1 second.
