Characteristics and Specifications 4
Electrical Specifications
U1731C/U1732C/U1733C User’s Guide 79
Capacitance specifications
Table 4 - 2 Capacitance specifications
Range Resolution
Accuracy = A
C
+ Offset
100 Hz 120 Hz 1 kHz 10 kHz 100 kHz
All models All models All models
U1733C and
U1732C only
U1733C only
20 mF 0.001 mF 0.5% + 8 0.5% + 8 - - -
2000 μF0.1 μF 0.5% + 5 0.5% + 5 0.5% + 8 - -
200 μF0.01 μF 0.3% + 3 0.3% + 3 0.5% + 5 0.5% + 8 -
20 μF0.001 μF 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5 5.0% + 10
2000 nF 0.1 nF 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3 0.7% + 10
200 nF 0.01 nF 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 3 0.7% + 10
20 nF 0.001 nF 0.5% + 5 0.5% + 5 0.2% + 3 0.5% + 3 0.7% + 10
2000 pF
[1]
0.1 pF 0.5% + 10 0.5% + 10 0.5% + 5 0.5% + 3 2.0% + 10
200 pF
[1]
0.01 pF - - 0.5% + 10 0.8% + 10 2.0% + 10
20 pF
[1]
0.001 pF - - - 1.0% + 20 2.5% + 10
Notes:
1 The accuracy for the 20 pF to 2000 pF range is specified after the Null function is used to subtract the stray capacitance of
the test leads.
2 The accuracy for the ceramic capacitor will be influenced depending on the dielectric constant (K) of the material used to
make the ceramic capacitor. For related influence factors, please refer to the Component dependency factors section in
the Impedance Measurement Handbook, downloadable for free at http://www.agilent.com/find/lcrmeters.
