Features and Functions 2
Additional Features
U1731C/U1732C/U1733C User’s Guide 43
Press the key for more than 1 second to activate the
high/low limit mode. The last- known set number (H## or
L##) will be indicated in the secondary display.
Figure 2-15 Using the Limit function
F10 5600 5040
F11 6800 6120
F12 8200 7380
F13 10000 9000
F14 12000 10800
F15 15000 13500
F16 18000 16200
Table 2 - 6 Factory default high and low limit values (continued)
Set High limit (H) Low limit (L)
The default values of the variable user sets are set to the same as the fixed
user sets. Use the Setup menu to change the high and low limits for each
set. See “Changing the user high/low limit values” on page 66 for more
information.
