Tolerance mode indicator for sorting L, C, or R
page 38
Tolerance set to 1% for sorting capacitance
Tolerance set to 5% for sorting capacitance
Tolerance set to 10% for sorting capacitance
Tolerance set to 20% for sorting capacitance
Data hold mode indicator page 40
Audible alert indicator for tolerance or limit
mode
page 71
Dissipation factor indicator
page 37
Quality factor indicator
Phase angle of impedance indicator
Secondary display -
Measurement units for the secondary display page 21
Impedance measurement indicator page 35
Inductance measurement indicator page 29
Capacitance measurement indicator page 31
Resistance measurement indicator page 33
