Setup Options 3
Setup Menu Summary
U1731C/U1732C/U1733C User’s Guide 55
H01 to H16 or L01 to L16
0 to 19999
Set the high and low limits for each variable user set.
See Table 3-4
on page 66 for the user default values.
page 66
9600 or 19200
Set the baud rate for remote communication with a PC
(9600 or 19200). Default is 9600.
page 68
En, nonE, or odd
Set the parity bit for remote communication with a PC
(even, none, or odd). Default is none.
page 69
7bit or 8bit
Set the data bit length for remote communication with a
PC (7-bit or 8-bit). Default is 8-bit.
page 70
2000 Hz, 3000 Hz, 4000 Hz,
or oFF
Set the LCR meter’s beep frequency (2000 Hz, 3000 Hz,
4000 Hz, or off). Default is 4000 Hz.
page 71
oFF or on Lock the LCR meter’s push buttons. Default is off. page 72
01 to 99 mins or oFF
Set the auto power-off time-out period from 1 to 99
minutes (1 hour, 39 minutes) or off. Default is 5 minutes.
page 73
01 to 99 s or oFF
Set the LCD backlight timeout period from 1 to 99 seconds
(1 minute, 39 seconds) or off. Default is 30 seconds.
dEFA Reset the LCR meter to its factory default settings. page 74
Table 3 - 2 Setup menu item descriptions (continued)
Legend Available settings Description Learn more on:
