Table 4: Installer Supplied Materials
AC power supply cable
to WPUs
1 Wire per Leg of Power (sized
per amperage rating)
Refer to Summary Electrical Ratings
DC power supply cable
to WPUs (DC supply fan
models only)
1 Wire per Leg of Power (sized
per amperage rating)
Refer to Summary Electrical Ratings
DC power supply cable
to controller box
2-Wire Conductor for Controller
Max current capacity 0.8A; 18AWG
recommended
Refer to Summary Electrical Ratings
DC Circuit Breaker (DC
supply fan models only)
Refer to Summary Electrical Ratings
DC Circuit Breaker for
controller
Breaker for the Controller
Max current capacity 0.8A
Communication cable
from controller box to
WPU
The ethernet (CAT5/5E/6) cable must
meet ANSI/TIA-568-B.2 standard
Alarm wiring harness
(Optional)
2-Wire Conductor (one per
alarm)
Alarm connection to controller box, 3
alarm inputs and 6 alarm outputs; all
alarm connections are optional
Single-Sided Adhesive Tape
Used to line the return and supply air
frames
Commercial Grade Outdoor
Silicone
For properly dressing cables and
harnesses
Refer to Appendix A: Air Frame
Drawing on Page 96
Built inside wall to facilitate air flow
Refer to Appendix A: Air Frame
Drawing on Page 96
Built inside wall to facilitate air flow
Hardware for Securing Unit to
Wall
Varies based on wall material and
thickness
Provides air tight seal around
return/exhaust & supply holes
Should be thick enough to
accommodate the rough finish of the
shelter exterior
IP Address for
Controller (Optional)
IP address and gateway for
controller
Required for Remote Monitoring. If
not supplied at install, a return trip is
required to establish communication.
IP Address for HVAC
(Optional)
IP address and gateway for each
HVAC unit
Required for remote software
upgrade of individual HVAC units. If
not supplied at install, a return trip is
required to establish communication.
