3. After installing the supply air grill, adjust the angle of the fins to direct airflow away from adjacent
equipment and prevent the supply air from bouncing back to the unit.
Remove the Compressor Brackets
Open the front, bottom panel on the WPU to locate the compressor. The two brackets at the base of the
compressor are required for transport only. Loosen the four bolts, remove the two brackets, and then
tighten the four bolts back down to the base of the compressor.
Figure 12: Remove Compressor Brackets
