Electrical Ratings (Wire Sizing)
Table 5: WPU Electrical Ratings
Model
Circuit #1
Circuit #2
AC
48VDC
AC
48VDC
MCA
MFS
MCA
MFS
MCA
MFS
MCA
MFS
11V1B3MR410AAC
30
40
--
--
--
--
--
--
11V1T3MR410AAC
29
40
--
--
--
--
--
--
15V1T4MR410AAC
34
50
--
--
--
--
--
--
15V1B4MR410AAC
36
50
--
--
--
--
--
--
28V2B5MR410AAC
36
50
--
--
29
40
--
--
28V1B5MR410BAC
23
30
--
--
40
60
--
--
28V1B5MR410CAC
25
35
--
--
--
--
--
--
Table 6: Controller Electrical Ratings
Model
Power Source
Max Power
Max Current
ASMUC.6
48VDC
50W
1.0A
ASMUC.6.DC
24VDC/48VDC
30W
1.3A/0.6A
ASMUC.6.AC
120VAC
90W
0.75A
