Hydrogen
Hydrogen alarm status
Alarm Outputs
High temp
High temp alarm status
HVAC Alarm 1
HVAC 1 alarm status
HVAC Alarm 2
HVAC 2 alarm status
HVAC Alarm 3
HVAC 3 alarm status
Filter
Filter alarm status
Drive Signal
Residual Press. Valve
Residual Pressure Valve Status
HVAC ID Select
Select Unit ID
Select the unit to view
Goto HVAC Info
Change “NO” to “YES” and press Enter to view unit status.
Controller info
SW ver.
Software version
OS ver.
Operating system version
BOOT ver.
Bootloader version
PRESS [ENTER] TO VIEW ADVANCED INFO
System info
Board type
Control board model
Board size
Control board size
Board temp
Control board temperature
Ret mem writes
Memory writes
Run Time
Controller
Controller operating hours
Power Off Info
Current time
Current time
Power off time
Last time the unit was powered off
Length last time off
Length of last unit shutdown
Viewing Unit Information
1. Information such as suction and discharge temperatures, system pressures, compressor speed,
and energy consumption can be viewed for all units from the controller.
Table 13 contains unit information that can be viewed either at the controller or directly at the unit. All
parameters are read-only.
2. Hold the Esc button until the main screen is displayed.
3. Press Up or Down until i is displayed in the bottom right of the screen and press Enter.
4. Press Down until “Select HVAC ID” is displayed on the screen and press Enter.
5. Use the Up or Down buttons to select the unit to be viewed and press Enter.
6. Press Down until the cursor is over “Goto HVAC Info” and press Enter.
