Alcatel-Lucent 7210 SAS-T User Manual

Alarm Port Pin Assignments
Page 92 7210 SAS-T Installation Guide
Figure 4: Example for Alarm Inputs Using an External Power Source
An example of the CLI commands to setup the alarm monitoring in the 7210SAS is
show below.
Please reference the 7210SAS Basic System Configuration Guide.
*A:M3>config>system# info
----------------------------------------------
#--------------------------------------------------
echo "System Configuration"
#--------------------------------------------------
