Installing the 7210 SAS-T
7210 SAS-T Installation Guide Page 43
Step 8 Ensure that PS1 and PS2 LEDs on the 7210 SAS-T front panel are lit if both the primary
and the redundant power supply has been plugged in.
Connecting to the Console Port
The RJ-45 serial port on the front panel is used to connect to the switch for out-of-band console
configuration. The on-board configuration program can be accessed from a terminal or a PC
running a terminal emulation program.
The pin assignments used to connect to the serial port are provided in Table 12.
Notes: If only one of the power supplies is plugged in, either PS1 or PS2 will be lit. PS1 will
be lit if the top slot has a PS plugged in and PS2 will be lit if the bottom slot has a PS plugged
in.
Table 12: Serial Cable Wiring
RJ45 Pin Usage
RTS 1 Used as defined. Should be connected
NC 2 Not used. Should not be connected
TXD 3 Used as defined. Should be connected
GND 4 Used as defined. Should be connected
GND 5 Used as defined. Should be connected
RXD 6 Used as defined. Should be connected
NC 7 Not used. Should not be connected
CTS 8 Used as defined. Should be connected
