Specifications
Page 80 7210 SAS-T Installation Guide
Specifications
Table 3: 7210 SAS-T Specifications
Item Width Height Depth
Physical dimensions
Size 17.17" (43.6 cm) 2.64" (1.5RU) (6.7 cm) 9.96" (25.3 cm)
Weight 11 lbs. (5 kg)
Environmental
Operating Temperature ETR variant: -40º C to 65º C (-49º F to 149º F) (standard) IEC 68-2-
14
Non-ETR variant: 0º C to 50º C (32º F to 122º F)
Humidity 5% to 95% non-condensing
Vibration IEC 68-2-36, IEC 68-2-6
Shock IEC 68-2-29
Drop IEC 68-2-32
Telcordia NEBS Design to meet NEBS level 3
Input
Input voltage -36VDC ~ -72VDC, Output: +12VDC
+20VDC ~ +28VDC, Output: +12VDC
100~240 V, 50~60 Hz, Output: +12VDC
Dual input power redundancy, with current sharing and hot-swap.
Maximum power
consumption
200 W
Typical power
consumption
90-110 W (depending
on configuration),
140-170 W (with
max PoE power
consumption)
