Initializing the System and Downloading Software
Page 60 7210 SAS-T Installation Guide
7210 SAS, please refer to the System Basics Guide. Additionally, you may want to store the
TiMOS image on the internal flash if you want to boot from the flash later.
You will need the following:
• A FTP server
•TiMOS image
• A PC with a serial port and Hyperterminal
• Cable that connects the console port of 7210 SAS-T to the serial port of PC
• A network cable to connect the 7210 unit to the network
The following sections describe how to boot the device using either of the options listed above.
Figure 1: 7210 SAS-T Boot Process
Prepare the set up as shown in the diagram above. Ensure that the console settings are set as shown
in Console Connection on page 70.
When you are done, power on the 7210 SAS-T.
Using the uplink port to boot 7210 from the network:
Resetting...OK
ø
Alcatel-Lucent 7210 Boot ROM. Copyright 2000-2009 Alcatel-Lucent.
All rights reserved. All use is subject to applicable license agreements.
Running POST tests from ROM
Testing ROM load area...done
OSSG325
FTP
Server
IP Address:
10.10.170.22/24
Port: 24
IP Address: 10.135.4.172/24
Gateway: 10.135.4.1
Console Cable
SAS-T
To Next Page
