Publication 0160-5.18 - June 2003
Using 160-DN2 with DeviceNet Scanner 6-33
Using Explicit Messaging
(Continued)
PLC-5 Example
Data Format for a Read and Write Parameter
The data in this example is for a Bulletin 160-SSC drive at MAC ID
1.
For a description of the content of the data file, refer to the
“Formatting Explicit Messages
” subsection starting on Page 6-23.
Request Data for Read of Drive Parameter 3
Response Data for Read of Drive Parameter 3
Request Data for Write to Drive Parameter 30
Response Data for Write to Drive Parameter 30
Address Value (hex) Description Refer to . . .
N30:0 0101 TXID = 01, Command = 01 (execute) 6-27
N30:1 0006 Port = 00, Size = 06 bytes 6-27
N30:2 0E01 Service = 0E (Get_Attribute_Single) B-21
Address = 01 (Drive Node Address) 6-27
N30:3 00B3 Class = B3 (160 Parameter Table Object) 6-27, B-18
N30:4 0001 Instance = 1 (Number of Instances) 6-27, B-18
N30:5 0003 Attribute = 03 (Parameter Number) 6-27, B-18
Address Value (hex) Description Refer to . . .
N30:70 0101 TXID = 01, Status = 01 (successful) 6-28
N30:71 0002 Port = 00, Size = 02 bytes 6-28
N30:72 8E01 Service = 8E (successful),
Address = 01 (Drive Node Address)
6-28
N30:73 0258 Response Data = 600 = 6.00 amperes
Address Value (hex) Description Refer to . . .
N30:0 0101 TXID = 01, Command = 01 (execute) 6-27
N30:1 0008 Port = 00, Size = 08 bytes 6-27
N30:2 1001 Service = 10 (Set_Attribute_Single) B-21
Address = 01 (Drive Node Address) 6-27
N30:3 00B3 Class = B3 (160 Parameter Table Object) 6-27, B-18
N30:4 0001 Instance = 1 (Number of Instances) 6-27, B-18
N30:5 001E Attribute = 30 (Parameter Number) 6-27, B-18
N30:6 07D0 Data = 2000 = 20.00 seconds
Address Value (hex) Description Refer to . . .
N30:70 0101 TXID = 01, Status = 01 (successful transaction) 6-28
N30:71 0000 Port = 00, Size = 00 bytes 6-28
N30:72 9001 Service = 90 (successful)
Address = 01 (Drive Node Address)
6-28
