Allen-Bradley DeviceNet 1761-NET-DNI - Mounting Template

1769-6.5
Specifications
A-3
Mounting Template
52.07 mm
(2.05 in)
27.7 mm
(1.09 in)
107 mm
(4.20 in)
118 mm
(4.64 in)
Allow 15 mm (0.6 in.)
clearance fo r D IN ra il
latch moveme nt durin g
installation a nd remo val.
