Chapter 9 Communication instructions
176 Rockwell Automation Publication 2080-RM001D-EN-E - February 2015
Ladder diagram
Structured Text (ST)
CIPAPPCFG data type
The following table describes the CIPAPPCFG data type.
Parameter Data type Description
Service USINT Service code:
1 – 127
Class UINT Logical segment’s Class ID value:
1 – 65535
Instance UDINT Logical segment’s Instance ID value:
0 – 4294967295
Attribute UINT Logical segment’s Attribute ID value:
1 - 65535, 0 - No Attribute ID used
