Allen-Bradley Micro800

Chapter 5 Arithmetic instructions
90 Rockwell Automation Publication 2080-RM001D-EN-E - February 2015
Neg converts a value to a negated value.
Arguments
Parameter Parameter Type Data Type Description
EN Input BOOL Function enable.
When Enable = TRUE, execute current convert to
negative computation.
When Enable = FALSE, there is no computation.
Applies only to LD programs.
i1 Input SINT - INT - DINT - LINT - REAL - LREAL Input and output must be the same data type.
o1 Output SINT - INT - DINT - LINT - REAL - LREAL Input and output must be the same data type.
ENO Output BOOL Enable out.
Applies only to LD programs.
Example
(* ST equivalence: *)
ao23 := - (ai10);
ro100 := - (ri1 + ri2);
Neg
