Allen-Bradley Micro800

Communication instructions Chapter 9
Rockwell Automation Publication 2080-RM001D-EN-E - February 2015 177
Parameter Data type Description
MemberCnt USINT Members ID count. Maximum Member ID values used:
1 - 3, 0 - No Member ID used
MemberId UINT[3] Member ID values:
0 - 65535
CIPCONTROLCFG data type
The following table describes the CIPCONTROLCFG data type.
Parameter Data type Description
Cancel BOOL TRUE - Cancel the execution of the function block.
Bit is cleared when the message is enabled.
TriggerType USINT Represents one of the following:
• 0: Msg Triggered Once (when IN goes from False to True)
• 1 to 65535: Cyclic trigger value in milliseconds. Msg is triggered periodically when IN is True. Set the
value to 1 to trigger the MSG as quickly as possible.
StrMode USINT Reserved for future use.
Message cancellation
If the Cancel parameter is set, and the message is enabled (EN bit is set) and not
done (DN bit is not set), then the message execution is aborted and the ER bit is
set.
CIP message triggering
A CIP message can be triggered periodically by setting a non-zero value to the
TriggerType parameter. The following table describes what happens when the
TriggerType parameter is used.
Action Results
Message is enabled Trigger timer starts
Trigger timer expires before the message
completes
Message is immediately triggered in the next ladder
scan cycle.
Message completes before the trigger time
expires
Message is triggered when the trigger time expires.
