Chapter 9 Communication instructions
226 Rockwell Automation Publication 2080-RM001D-EN-E - February 2015
Creating a MSG_CIPGENERIC messaging program
Perform the following tasks to create a MSG_CIPGENERIC messaging program
that can be used to read information from a different controller.
No Task
1
Identify initial values for the input variables (MSG_CIPGENERIC) on page 227
2
Add a MSG_CIPGENERIC function block and variables on page 227
3
Configure initial values for variables on page 229
4
Add a contact and a coil on page 234
5
Add a COP function block, variables and contact (MSG_CIPGENERIC) on page 235
6
Verify correct IP configuration on Controller B on page 236
Creating a MSG_CIPGENERIC messaging program
Perform the following tasks to create a MSG_CIPGENERIC messaging program
that can be used to read information from a different controller.
No Task
1
Identify initial values for the input variables (MSG_CIPGENERIC) on page 227
2
Add a MSG_CIPGENERIC function block and variables on page 227
3
Configure initial values for variables on page 229
4
Add a contact and a coil on page 234
5
Add a COP function block, variables and contact (MSG_CIPGENERIC) on page 235
6
Verify correct IP configuration on Controller B on page 236
