Chapter 11 Counter instructions

272 Rockwell Automation Publication 2080-RM001D-EN-E - February 2015

Structure Text

(* ST Equivalence: CTU1 is an instance of CTU block*)

CTU1(trigger,NOT(auto_mode),100);

overflow := CTU1.Q;

result := CTU1.CV;

Results
